Blade Fusion 700 Kit with Motor and Blades

The Fusion 700 delivers the pinnacle of Blade helicopter performance along with a perfect fusion of convenience and value with the included blades and motor.

In the Box

Blade Fusion 700 Helicopter Kit x1
Spektrum Avian 4735-540Kv 10-Pole Brushless Outrunner Motor (included) x1
Blade 700 mm Carbon Fibre Main Rotor Blade Set (included) x1
Blade 105 mm Carbon Fibre Tail Rotor Blade Set (included) x1
Foam Blade Holder (included) x1
Blade Fusion 700 Kit Manual x1

Needed to Complete

Full-range 6+ channel Transmitter x1
Flybarless Control System with Built-In and/or External Receiver x1
120A+ 12S Brushless Helicopter Compatible ESC x1
High-Torque Standard Sized Cyclic Servos x3
High-Speed Standard Sized Tail Servo x1
6S 22.2V or (1) 12S 44.4V 4000–5000mAh LiPo Battery with EC5 or IC5 Connector x2
Compatible LiPo Charger x1

Features

Extremely strong and durable carbon fibre and aluminium airframe design
High-strength steel 15 mm main shaft and 10 mm spindle with metal head components
Ovalised aluminium tail boom eliminates the need for boom supports
8 mm wide belt for the driven tail featuring adjustable tension
High-strength steel 6 mm tail shaft paired with a metal bell crank and grips
Efficient Delrin helical main gear paired with a steel pinion for quiet and reliable performance
Compatible with popular and common 12S 4000–5000mAh LiPo battery setups
Aluminium tail case with a metal tail drive pulley
5 mm diameter carbon fibre tail pushrod for precise tail control
Includes a 4735-540Kv outrunner motor compatible with popular 12S battery setups
Precision machined Delrin helical main gear with 11- and 12-tooth pinion gears
Black anodised aluminium swashplate and other components
Includes 700 mm carbon fibre main rotor blades
Sprag autorotation clutch and machined rotor head dampers with O-rings
High-strength steel 15 mm main shaft and 10 mm spindle/feathering shaft
Aluminium blade grips with zero pitch indicator marks
All-metal and 2 mm thick carbon fibre construction
2-piece white moulded landing gear plus a painted fibreglass canopy for excellent visibility
Reinforced machined aluminium main shaft bearing block assembly
Sliding carbon fibre battery tray with positive locking mechanism
Ovalised aluminium tail boom for added strength and rigidity without boom supports
Machined aluminium tail case and separate painted vertical fin for improved visibility
8 mm wide drive belt with adjustable tension drives a large aluminium pulley
Includes 105 mm carbon fibre tail rotor blades
Belt-driven tail rotor for lower weight, fewer parts, and easier maintenance
6 mm high-strength steel tail shaft with metal bell crank, hub, and grips
5 mm carbon fibre tail pushrod with ball links for precise control
Hidden tail servo for added protection and a sleek look

More Information

Like the Fusion series models that came before it, the top-of-the-line Blade Fusion 700 blends the lines between convenience and capabilities, plus quality and value. The extremely strong carbon fibre and aluminium airframe is ready to pair with the included blades and motor, and popular 12S battery setups, to deliver exhilarating performance with power to spare. Now you can make the dream of owning a 700-sized helicopter with cutting-edge capabilities – along with incredible durability and reliability – a reality!

Designed with nearly two decades of engineering and development experience, the Fusion 700 offers the pinnacle of Blade helicopter performance. It packs modern-day high-performance features into a high-quality, rugged, and reliable airframe that’s ready to deliver pro-level flight performance for sport, precision, and aggressive 3D flying. The extremely durable carbon fibre and aluminium airframe design assembles quickly, plus it’s easy to maintain and repair. The Delrin helical main gear is driven by the included 4735-540Kv brushless outrunner motor that delivers incredible torque and performance with popular 12S or two pieces of 6S 4000-5000mAh LiPo battery setups. A belt-driven tail assembly featuring machined aluminium construction ensures locked-in tail performance on every flight. So whether you’re an intermediate pilot moving up to your first-ever 700-sized model, or you’re already a world-class 3D pilot, the Fusion 700 delivers an unmatched combination of convenience, capabilities, quality, and value!

Specifications

Approximate Assembly Time: 5-7 Hours
Battery: Sold Separately
Canopy/Body Material: Fibreglass
Charger: Sold Separately
Completion Level: Kit
Gear Ratio: 9.33-10.18
Main Blade Material: Carbon Fibre
Main Frame Material: Carbon Fibre
Main Motor Type: Brushless
Main Rotor Blade Length: 700 mm (27.56")
Main Rotor Diameter: 1575 mm (62")
Main Rotor Head Type: Collective Pitch Flybarless
Motor Size: 4735-540Kv 10-Pole
Power Type: Electric
Product Height: 378 mm (14.88")
Product Length: 1384 mm (54.5")
Product Weight: With recommended battery: 5.7 kg (12.5 lb)
Product Width: 216 mm (8.5")
Receiver: Sold Separately
Recommended Motor Battery: 12S 44.4V 4000mAh to 5000mAh LiPo (SPMX-1091)
Servos: Sold Separately
Skill Level: Level 4
Speed Control: Sold Separately
Swashplate Type: 120 Degree CCPM
Tail Blade Material: Carbon Fibre
Tail Drive: Belt Drive
Tail Rotor Blade Length: 105 mm (4.13")
Tail Rotor Diameter: 292 mm (11.5")
